1Sash width：450mm-1200mm
2Sash High：500mm-2200mm
3Max Sash weight：110kg
1Visual surface size：
Ø Window frame：29mm
Ø Window sash：72mm
2Profile width：
Ø Frame：87mm
Ø Sash:97mm
3Range of total glass thickness：40mm-59mm
4Insulation strip size：44mm
Typical Window type products U-value：1.1 -1.3W/(·K) （Depending on the glass configuration, the insulation performance of the entire window varies depending on the glass configuration）
1Realize three high-speed rail grade composite foam rubber strips, with the middle rubber strip fully utilizing the principle of equal pressure to achieve efficient sealing effect；
2The design of anti pry lock points achieves a powerful locking structure, giving the product excellent anti-theft effect；
3Standardized processing technology, perfect balance between efficiency and quality；
4Multiple auxiliary materials combined to meet the demand for ultra-low energy consumption and ultra large grid division；
Product Category | 1 level | 2 level | ||
Product Name | 87Series Casement Windows | Aluminum Windows and Doors | Aluminum Windows |
Technical Specifications
Thickness | 1.8mm | Window frame | Ø 29mm |
Bearing | 110KG | Window sash | Ø 72mm |
Blade width | 451-200mm | Frame | 87mm |
Blade height | 500-2200mm | Sash | Ø 97mm |
Standard glass | 40-59mm | U-value | 1.1 -1.3W/(·K) |
Hardware | TODN | ||
Themal Insulation Performance(UW) | 1.0-1.2W/m²K | ||
Wind Pressure Resistance Performance | +5000Pa | ||
Acoustic Insulation Performance | Rw up to 40dB | ||
Water tightness Performance | +700Pa | ||
Air tightness/(m·h） | q10≤ 0.5m³ |
Packaging Material
PE Film | ||||
PVC Corner Protector |
